Soundcard Prsonus Studio 1824c

Our expandable 18x18, 24-bit / 192 kHz, USB-C recording audio interface with studio-grade converters, pristine XMAX-L solid-state mic preamps, and professional LED monitoring.

Up to 18 inputs/20 outputs simultaneously (8x8 at 192 kHz)
2 mic/instrument/line inputs with XMAX Class A mic preamps
6 mic/line inputs with XMAX Class A mic preamps
8 channels of ADAT Optical I/O (4 channels at 96 kHz)
2 balanced ¼-inch TRS main outputs and 8 balanced ¼-inch TRS line outputs for monitor mixing, all DC coupled for sending control voltages
2 stereo headphone outputs with individual level controls
Stereo S/PDIF digital I/O and MIDI In/Out
18x8 onboard DSP monitor mixer
Front-panel level controls plus Mono and Mute buttons for the main outputs
True 48V phantom power for condenser microphones (global)
10 ladder-style 8-LED level meters (8 input, 2 main output)
24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
Professional Recording Software Included - Studio One Pro License

Connectivity: USB-C®
Headphone Jack: 1/4" TRS Active Stereo
Inputs: Eight - Eight Combo Mic/Instrument/Line Inputs (XLR Female Balance, 1/4" TS Female Unbalanced (Inst))
Line Out: Four - 1/4" TRS Balanced, DC Coupled
Phantom Power: +48 VDC
VoltageRequirements: 100-240 VAC, 50-60 Hz
Instrument Inputs Dynamic Range: 112 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response: 20 Hz - 20 kHz (Minimum Gain)
Instrument Inputs Gain Range: 80 dB
Instrument Inputs Maximum Level: +15 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range: 112 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response: 20 Hz - 20 kHz (Unity Gain)
Line Inputs Gain Range: 40 dB
Line Inputs Impedance: 10 kΩ
Line Inputs Maximum Level: +21 dBu (Balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion: 0.005% (1 kHz, +18 dBu, Minimum Gain)
Microphone Input Connection Type: XLR Female (Combo), Balanced
Microphone Preamp Dynamic Range: 110 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise: -128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)
Microphone Preamp Frequency Response: 20 Hz - 20 kHz (Unity Gain)
Microphone Preamp Gain Control Range: 80 dB
Microphone Preamp Input Impedance:1.4 kΩ
Microphone Preamp Maximum Input Level: +16 dBu, Minimum Gain
Microphone Preamp Total Harmonic Distortion:0.005% (1 kHz, 0dBu, Unity Gain)
Headphone Outputs Dynamic Range: 103 dB (A-weighted, 1 kHz, Unity Gain)
Headphone Outputs Frequency Response: 20 Hz - 20 kHz (Unity Gain)
Headphone Outputs Impedance Working Range: 32Ω to 600Ω
Headphone Outputs Maximum Output: 150 mW/Channel (60Ω Load)
Headphone Outputs Total Harmonic Distortion:0.250% (1 kHz, 150 mW, Unity Gain)
Line Outputs Connection Type: 1/4" TRS Female
Main And Line Outputs Dynamic Range:108 dB (A-Weighted, Unity Gain)
Main And Line Outputs Frequency Response:20 Hz - 20 kHz (Unity Gain)
Main And Line Outputs Maximum Level: +18 dBu (Balanced)
Main And Line Outputs Total Harmonic Distortion:0.004% (1 kHz, -1 dBFS, Unity Gain)
Main Outputs Connection Type: 1/4" TRS Female
